SS CORRUGATED FLEXIBLE HOSE

PRODUCT NOMENCLATURE

STANDARD CORRUGATED FLEXIBLE METAL HOSE

Structure

Annular corrugated flexible metal hoses can be produced from longitudinally welded tubes corrugated mechanically with or with out braiding

Standards

We are following EN ISO 10380 for stainless steel corrugated flexible hoses

Hose material

Stainless steel AISI 304, AISI 321 and AISI316L

Braiding material

Stainless steel AISI 304 and 316 L

Product supplied Coils

DN6-25 -15m, 25m, 30m and 50m DN32-50 -15m, 25m,30m and 50m DN65-100 -25m

Note: Please contact our sales team for specific lengths
